MIL-DTL-16377/8C(SH)
TABLE V. First article and comparison inspection for window assemblies. 1/
Tests
Requirement
Test Method
Remarks
Examination
3.13
4.5
Optical uniformity
3.7.7.1
4.8.4
Stress relief
3.8.5.3
4.8.5
Shock
3.5.12
4.8.7
Vibration
3.5.13
4.8.8
Enclosure effectiveness
3.5.11
4.8.14.4
Watertight
Light output
3.7.1
4.8.6.1
Candlepower
NOTE:
1/
Requirements and test method paragraph numbers refer to MIL-DTL-16377.
TABLE VI. Part number and general information.
Military Part 1/
National Stock
Item Name
Remarks
Number (NSN)
Number M16377/8-
2/
331.1
Complete fixture, Symbol 331.1
6210-00-548-0598
2/
331.2
Complete fixture, Symbol 331.2
6210-01-088-2511
347.2
Complete fixture, Symbol 347.2
6210-01-088-6945
347.3
Complete fixture, Symbol 347.3
6210-01-088-6186
331.1SSL
Complete fixture, solid state, Symbol 331.1SSL
New
331.2SSL
Complete fixture, solid state, Symbol 331.2SSL
New
347.2SSL
Complete fixture, solid state, Symbol 347.2SSL
New
347.3SSL
Complete fixture, solid state, Symbol 347.3SSL
New
3/
001
Window, white diffusing
6210-00-548-0601
003
Window, clear and white prismatic
6210-01-438-2960
NOTES:
1/
Military part numbers M16377/8-347, 347.1, and 002 have been superseded by military part numbers
M16377/8-347.2, 347.3, and M16377/67-001, respectively.
2/
Formerly covered on Drawing NAVSHIPS 9000-S6401-74482 and MS17194.
3/
Formerly covered on MS16891-40.
10
