MIL-DTL-16377/9B(SH)
EXAMINATION AND TESTS:
Examinations and tests shall be as specified in MIL-DTL-16377 and the following:
First article inspection:
Complete fixtures:
Window assemblies:
See table IV.
Conformance:
Comparison inspection:
Same as first article inspection.
Conformance inspection:
See MIL-DTL-16377.
GENERAL INFORMATION:
Assignment of military part numbers and general information is shown in table V.
TABLE I. Standard parts.
Specification or Military
National Stock
Name
Remarks
Part Number
Number (NSN)
Lamp
ANSI/ANSLG C78.81
6240-00-299-5546
Industry number
F8T5/CW
Lamp lock
M16377/40-001
6250-00-399-7039
Lampholder
UL 496
6250-00-377-8590
SUPP. SA, FIG. SA2.1
Startersocket
UL 496
6250-00-295-2738
SUPP. SA, FIG. SA2.4
Starter
NEMA ANSI C78.180
6250-00-299-5962
Commercial
designation: FS5
Ballast
M16377/45-001
6250-00-295-2735
M16377/41-009 or
6210-00-973-1747
See 3.5.16 of
Shock mount
M16377/41-010
6210-00-973-1748
MIL-DTL-16377
Red filter tube
M16377/42-001
6210-00-399-6297
Not furnished, see 3.7.9
of MIL-DTL-16377
Broad band blue filter
M16377/42-002
6210-00-503-2810
Not furnished, see 3.7.9
tube
of MIL-DTL-16377
Gray filter tube
M16377/42-014
6210-01-313-8170
Not furnished, see 3.7.9
(2.5% transmission)
of MIL-DTL-16377
Gray filter tube
M16377/42-013
6210-01-351-3943
Not furnished, see 3.7.9
(1% transmission)
of MIL-DTL-16377
7
