MIL-DTL-3661D
1.2.2.4 Material. The lens material will be identified by a one-digit number in accordance with table III
(see 3.2).
TABLE III. Lens Material.
Symbol
Material
Plastic (-55C. to +71C.)
2
Plastic (-55C. to +125C.)
3
1.2.3 Type designation of indicator lights (non-replaceable lens type). The type designation for indicator
lights with non-removable lens and nomenclature display types will be in the following form and as specified (see
LHC82
/1
BT2
Style
Type
(1.2.2.2
(1.2.3.1)
(1.2.1.2)
To 1.2.2.4)
1.2.3.1 Style. The style is identified by a three-letter symbol "LHC" followed by a two-digit number.
2. APPLICABLE DOCUMENTS
2.1 General. The documents listed in this section are specified in sections 3 and 4 of this specification.
This section does not include documents in other sections of this specification or recommended for additional
information or as examples. While every effort has been made to ensure the completeness of this list, document
users are cautioned that they must meet all specified requirements documents cited in sections 3 and 4 of this
specification, whether or not they are listed.
2.2 Government documents.
2.2.1 Specifications, standards and handbooks. The following specifications, standards and handbooks
form a part of this document to the extent specified herein. Unless otherwise specified, the issues of these
documents are those listed in the issue of the Department of Defense Index of Specifications and Standards
(DODISS) and supplement thereto, cited in the solicitation (see 6.2).
INTERNATIONAL ORGANIZATION FOR STANDARDIZATION (ISO)
ISO10012 Measurement management systems
Requirements for measurement processes and measuring Equipment First
Edition
AENOR UNE-EN ISO/IEC 17025 Conformity assessment. General requirements for the
competence of testing and calibration laboratories
(Copy of this document is available from www.iso.org or the International Organization for Standardization
American National Standards Institute, 11 West 42nd Street, 13th Floor, New York, NY 10036, United States.)
FEDERAL STANDARDS
FED-STD-3 - Colors, Aeronautical Lighting
FED-STD-595/36231 Gray, Flat or Lusterless
FED-STD-595/37038 Black, Flat or Lusterless
(Copies of these documents are available online at https://quicksearch.dla.mil/)
COMMERCIAL ITEM DESCRIPTION
3
