MIL-DTL-16377/11C(SH)
TABLE V. First article and comparison inspection for window assemblies. 1/
Test
Requirement
Test Method
Remarks
Examination
3.13
4.5
Optical uniformity
3.7.7.1
4.8.4
Stress relief
3.8.5.3
4.8.5
Shock
3.5.12
4.8.7
Vibration
3.5.13
4.8.8
Enclosure effectiveness
3.5.11
4.8.14.4
Watertight
Light output
3.7.1
4.8.6.1
Candlepower
NOTE:
1/
Requirement and test method paragraph numbers refer to MIL-DTL-16377.
TABLE VI. Part number and general information.
Military Part 1/
National Stock
Number
Item Name
Remarks
Number (NSN)
M16377/11-
2/
77.4
Complete fixture, Symbol 77.4
6210-00-215-6355
2/
77.5
Complete fixture, Symbol 77.5
6210-01-088-2510
344.2
Complete fixture, Symbol 344.2
6210-01-149-4168
344.3
Complete fixture, Symbol 344.3
6210-01-465-6697
77.4SSL
Complete fixture, solid state, Symbol 77.4SSL
New
77.5SSL
Complete fixture, solid state, Symbol 77.5SSL
New
344.2SSL
Complete fixture, solid state, Symbol 344.2SSL
New
344.3SSL
Complete fixture, solid state, Symbol 344.3SSL
New
3/
001
Window assembly, white diffusing
6210-00-399-7035
003
Window assembly, clear and white prismatic
6210-01-169-5997
NOTES:
1/
Military part number M16377/11-344, 344.1, and 002 have been superseded by military part numbers
M16377/11-344.2, 344.3, and M16377/67-004, respectively.
2/
Formerly covered on Drawing NAVSHIPS 9000-S6401-74363 and MS17179.
3/
Formerly covered on M616891-30.
