MIL-DTL-16377-11 Fixtures, Lighting; Fluorescent And Ssl Equivalent, General Lighting, 40 Watts, 120 Volts, 60 Hertz, Watertight, Symbols 77.4, 77.5, 344.2, 344.3, 77.4Ssl, 77.5Ssl, 344.2Ssl, And 344.3Ssl

Pages 1 - 2 - 3 - 4 - 5 - 6 - 7 - 8 - 9 - 10 - 11 - 12 - 13 - 14 - 15


MIL-DTL-16377/11C(SH)
TABLE I. Numerical candela distribution for symbols 77.4, 77.5, 344.2, 344.3.
Candlepower
Candlepower
Angle
Symbol Number
Angle
Symbol Number
77.4, 77.5
344.2, 344.3
77.4, 77.5
344.2, 344.3
0
560
590
65
230
240
5
550
590
70
180
190
10
550
590
75
135
140
15
540
590
80
90
100
20
520
580
85
60
90
25
505
570
90
50
50
30
470
550
95
30
42
35
450
530
100
25
20
40
410
500
105
20
10
45
385
460
110
10
0
50
350
410
115
0
0
55
310
360
120
0
0
60
265
300
125
0
0
4
