MIL-DTL-16377/12C(SH)
270°
90°
90°
270°
100
280°
80°
80°
280°
200
SYMBOLS 333.1, 333.2
70°
290°
290°
70°
300
SYMBOLS 342.2, 342.3
300°
60°
400
60°
300°
500
310°
50°
600
50°
310°
700
800
320°
40°
40°
320°
900
0
330°
340°
350°
10°
20°
30°
30°
20°
10°
350°
340°
330°
PHOTOMETRIC TEST DATA:
Distance:
10 feet.
Plane:
At right angles to long axis of luminaire through geometric center of luminaire.
Voltage:
115 volts, 60 hertz.
Ambient temperature:
77 °F (25 °C).
Fluorescent lamps:
Use lamps furnished with fixture seasoned for at least 100 hours.
Fluorescent ballast:
Use ballast furnished with fixture.
Fluorescent lamp correction:
Distribution curves based on 1,280 lumens per lamp.
SSL:
No seasoning required for LEDs.
FIGURE 10. Candlepower distribution curves for symbols 333.1, 333.2, 342.2, and 342.3.
7
