MIL-DTL-16377/26B(SH)
TABLE I. First article and comparison inspection for type I fixtures. 1/
Test
Requirement
Test Method
Remarks
Examination
3.13
4.5
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
2/, 3/
Enclosure effectiveness
3.5.11
4.8.14
2/
Shock
3.5.12
4.8.7
2/
Vibration
3.5.13
4.8.8
2/, 3/
Enclosure effectiveness
3.5.11
4.8.14
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
Continuity of grounding
3.6.13.4
4.8.12
Optical uniformity
3.7.7.1
4.8.4
Mechanical shock
3.7.7.6
4.8.17.3
8 ft-lbs
Thermal shock
3.7.7.7
4.8.17.4
Breakage pattern
3.7.7.9
4.8.17.6
Color and luminous transmittance
3.7.3
4.8.6.3
Symbol 113 and
113.1 only
Light output
3.7.1
4.8.6.1
Symbol 112 only
Candlepower
Magnetic permeability
3.4.8
4.8.18
NOTES:
1/
Requirement and test method paragraph numbers refer to MIL-DTL-16377.
2/
In accordance with 4.3.1 of MIL-DTL-16377, tests shall be performed on one luminaire in the
order specified.
3/
Watertight.
