MIL-DTL-16377/27C(SH)
EXAMINATION AND TESTS:
Examination and tests shall be as specified in MIL-DTL-16377 and as follows:
First article inspection:
Globes:
See table III.
Conformance:
Comparison inspection:
Same as first article inspection.
Conformance inspection: See MIL-DTL-16377.
GENERAL INFORMATION:
a.
Assignment of military part numbers and general information is shown in table III.
b.
Fixtures may be adapted for bulkhead mounting by using the bracket shown on figure 3.
TABLE I. First article and comparison inspection for complete type I fixtures. 1/
Test
Requirement
Test Method
Remarks
Examination
3.13
4.5
Operation
3.13
4.8.1
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
2/, 3/
Enclosure effectiveness
3.5.11
4.8.14
2/
Shock
3.5.12
4.8.7
2/
Vibration
3.5.13
4.8.8
2/, 3/
Enclosure effectiveness
3.5.11
4.8.14
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
Continuity of grounding
3.6.13.4
4.8.12
Optical uniformity
3.7.7.1
4.8.4
Mechanical shock
3.7.5.6
4.8.17.3
8 ft-lbs
Thermal shock
3.7.5.7
4.8.17.4
Breakage pattern
3.7.5.9
4.8.17.6
Color and luminous
3.7.3
4.8.6.3
Symbol 93.2, 93.4, and
transmittance
93.5 only
Light output
3.7.1
4.8.6.1
Symbol 92.2 only
Candlepower
Magnetic permeability
3.4.8
4.8.18
NOTES:
1/
Requirement and test method paragraph numbers refer to MIL-DTL-16377.
2/
In accordance with 4.3.1 of MIL-DTL-16377, tests shall be performed on one luminaire in the
order specified.
3/
Watertight.
