MIL-DTL-16377/27C(SH)
TABLE II. First article and comparison inspection for type III luminaires. 1/
Test
Requirement
Test Method
Remarks
Examination
3.13
4.5
Operation
3.13
4.8.1
Power interface
3.6.18
4.8.21
Power quality
3.6.18.1
4.8.22
Voltage transient spike
3.6.18.2
4.8.23
Electromagnetic interference
3.6.14
4.8.16
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
2/, 3/
Enclosure effectiveness
3.5.11
4.8.14
2/
Shock
3.5.12
4.8.7
2/
Vibration
3.5.13
4.8.8
2/, 3/
Enclosure effectiveness
3.5.11
4.8.14
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
2/
Noise
3.5.14
4.8.9
Continuity of grounding
3.6.13.4
4.8.12
Photometrics
3.7.1
4.8.6
Candlepower
Brightness
3.7.5
4.8.6.4
Chromaticity
3.7.4
4.8.6.5
Correlated color temperature (CCT)
3.7.4.1.1
4.8.6.6
Lumen maintenance
3.7.11
4.8.20
Fail-safe circuit design
3.17
4.8.24
Optical uniformity
3.7.7.1
4.8.4
Mechanical shock
3.7.7.6
4.8.17.3
8 ft-lbs
Thermal shock
3.7.7.7
4.8.17.4
Breakage pattern
3.7.7.9
4.8.17.6
Color and luminous transmittance
3.7.3
4.8.6.3
Symbol 93.2SSL,
93.4SSL, and 93.5SSL
only
Stress relief
3.8.5.3
4.8.5
Magnetic permeability
3.4.8
4.8.18
Salt spray
3.5.15
4.8.10
NOTES:
1/
Requirement and test method paragraph numbers refer to MIL-DTL-16377.
2/
In accordance with 4.3.1 of MIL-DTL-16377, tests shall be performed on one luminaire in the order
specified.
3/
Watertight.
13
