MIL-DTL-16377/7B(SH)
TABLE IV. First article and comparison inspection for window assemblies. 1/
Test
Requirement
Test Method
Remarks
Examination
3.13
4.5
Optical
3.7.6.1.1
4.8.4
Stress relief
3.8.5.3
4.8.5
Shock
3.5.12
4.8.7
Vibration
3.5.13
4.8.8
Enclosure effectiveness
3.5.11
4.8.14.4
Watertight
Light output
3.7.1
4.8.6.1
Candlepower
NOTE:
1/
Requirements and test method paragraph numbers refer to MIL-DTL-16377.
TABLE V. Part number and general information.
Military Part
National Stock
Item Name
Remarks
Number M16377/7-
Number (NSN)
1/
70.3
Complete fixture, Symbol 70.3
6210-01-595-3961
1/
70.4
Complete fixture, Symbol 70.4
6230-01-511-3184
70.4S
Complete fixture, Symbol 70.4 with toggle switch
6210-01-484-6855
1/
78.2
Complete fixture, Symbol 78.2
6210-00-669-6526
336
Complete fixture, Symbol 336
6210-01-149-4169
336.1
Complete fixture, Symbol 336.1
6230-01-510-9625
70.3SSL
Complete fixture, solid state, Symbol 70.3SSL
70.4SSL
Complete fixture, solid state, Symbol 70.4SSL
78.2SSL
Complete fixture, solid state, Symbol 78.2SSL
336SSL
Complete fixture, solid state, Symbol 336SSL
336.1SSL
Complete fixture, solid state, Symbol 336.1SSL
2/
001
Window assembly, white diffusing
6210-00-500-0742
002
Window assembly, clear and white prismatic
6210-01-510-9785
NOTES:
1/
Formerly covered on NAVSHIPS Drawing 9000-86401-74481 and MS17120.
2/
Formerly covered on MS16891.
10
