MIL-DTL-16377/7B(SH)

EXAMINATION AND TESTS:

Examinations and tests shall be as specified in MIL-DTL-16377 and the following:

First article inspection:

Complete fixtures:

See table II for Type I and table III for Type III.

Window assemblies:

See table IV.

Conformance:

Comparison inspection:

Same as first article inspection.

Conformance inspection:

See MIL-DTL-16377.

GENERAL INFORMATION:

Assignment of military part numbers and general information is shown in table V.

TABLE I. Standard parts.

Specification or Military

National Stock

Name

Remarks

Part Number

Number (NSN)

Lamp

ANSI/ANSLG C78.81

6240-00-299-5546

Industry number

F8T5/CW

Lamp lock

M16377/40-001

6250-00-399-7039

Lampholder

UL 496

6250-00-377-8590

SUPP. SA, FIG. SA2.1

Startersocket

UL 496

6250-00-295-2738

SUPP. SA, FIG. SA2.4

Starter

NEMA ANSI C78.180

9250-00-299-5962

Commercial

designation: FS 5

Ballast

M16377/45-001

6250-00-295-2735

Shock mount 1/

M16377/41-009 or

6210-00-973-1747

See 3.5.16 of

M16377/41-010

6210-00-973-1748

MIL-DTL-16377

Red filter tube

M16377/42-001

6210-00-399-6297

Not furnished, see 3.7.9

of MIL-DTL-16377

Blue filter tube

M16377/42-002

6210-00-503-2810

Not furnished, see 3.7.9

of MIL-DTL-16377

Gray filter tube

M16377/42-014

6210-01-313-8170

Not furnished, see 3.7.9

(2.5% transmission)

of MIL-DTL-16377

Gray filter tube

M16377/42-013

6210-01-351-3943

Not furnished, see 3.7.9

(1% transmission)

of MIL-DTL-16377

Switch, toggle, DPST

MS16569-1

5930-00-719-9659

For Symbol 78.2 and

78.2SSL only

NOTE:

Shock mounts are not required for Symbol 78.2.
