MIL-DTL-16377/7B(SH)
TABLE II. First article and comparison inspection for complete type I fixtures. 1/
Test
Requirement
Test Method
Remarks
Examination
3.13
4.5
Operation
3.13
4.8.1
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
2/
Enclosure effectiveness
3.5.11
4.8.14.4
Watertight
2/, 3/
Shock
3.5.12
4.8.7
2/
Vibration
3.5.13
4.8.8
2/
Enclosure effectiveness
3.5.11
4.8.14.4
Watertight
2/
Dielectric withstanding voltage
3.6.15
4.8.2
2/
Insulation resistance
3.6.16
4.8.3
2/
Noise
3.5.14
4.8.9
Grounding circuit
3.6.13.3
4.8.11
Symbol 78.2 only
Continuity of grounding
3.6.13.4
4.8.12
Symbol 78.2 excluded
Optical uniformity
3.7.6.1.1
4.8.4
Stress relief
3.8.5.3
4.8.5
Light output
3.7.1
4.8.6.1
Candlepower
Magnetic permeability
3.4.8
4.8.18
NOTES:
1/
Requirement and test method paragraph numbers refer to MIL-DTL-16377.
2/
In accordance with 4.3.1 of MIL-DTL-16377, tests shall be performed on one luminaire in the
order specified.
3/
Symbols 70.3, 70.4, 336, and 336.1 shall withstand Grade A. Symbol 78.2 shall withstand
Grade B.
