MIL-DTL-3661 Lampholders, Indicator Lights, Indicator Light Housing, And Indicator Light Lenses, General Specification ForThis specification covers the general requirements for lampholders, indicator lights, indicator-light housings, and indicator-light lenses including display and integral lamp driver network types and associated hardware. For the purpose of this specification, an indicator-light housing is an indicator light without a lens \(see 6.5\).

Pages 1 - - 4 - 5 - 6 - 7 - 8|||9 - 10 - 11 - 12 - 13 - 14 - 15 - 16 - 17 - 18 - 19 - 20 - 21 - 22|||


. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
MIL-DTL-3661D
TABLE IV. First Article Tests.
Examination and tests
Requirement paragraph
Method paragraph
Group I (All 12 sample units)
Visual and mechanical examination
incl., 3.6 and 3.7
Contact resistance
Luminance
Circuit continuity
Group II (3 sample units from group I )
Bushing torque
Temperature cycling
Solderability
Sand and dust
Terminal strength
Lens torque
Dimmer torque
Socket shell torque
Contact resistance
Dielectric withstanding voltage
Group III (3 sample units from group I )
Bushing torque
Terminal strength
Vibration
Shock (method I or II as specified)
Contact resistance
Dimmer torque
Lens torque
Dielectric withstanding voltage
Group IV (3 sample units from group I )
Contact spring pressure
Life (mechanical)
Life (electrical)
Press-to-test operation
Sealing
Contact resistance
Lens torque
Dimmer torque
Dielectric withstanding voltage
Salt spray (corrosion)
Group V (3 sample units from group I)
Moisture resistance
Sealing
Dielectric withstanding voltage
1
As applicable.
2
When specified (see 3.2).
