MIL-DTL-16377J(SH)
TABLE III. Component substitution for high-temperature fluorescent lighting fixtures.
Fluorescent Lighting Fixtures Using
Fluorescent Lighting Fixtures Using
the 6 or 8 Watt Fluorescent Lamps
the 15 or 20 Watt Fluorescent Lamps
Component
Use
In Lieu of
Use
In Lieu of
Lampholders
UL 496, (naval-use
UL 496, (naval-use
UL 496, (naval-use
UL 496, (naval-use
lampholders,
lampholders,
lampholders,
lampholders,
302 °F [150 °C])
221 °F [105 °C])
302 °F [150 °C])
221 °F [105 °C])
Starter sockets
UL 496, (naval-use
UL 496, (naval-use
UL 496, (naval-use
UL 496, (naval-use
starter holders,
starter holders,
starter holders,
starter holders
302 °F [150 °C])
221 °F [105 °C])
302 °F [150 °C])
221 °F [105 °C])
Ballasts
M16377/45-002 of
M16377/45-001 of
M16377/72-002 of
M16377/72-001 of
MIL-F-16377/45
MIL-F-16377/45
MIL-DTL-16377/72
MIL-DTL-16377/72
Internal wiring
Wire with silicone
Wire with
Wire with silicone
Wire with
impregnated fiber-glass
thermoplastic
impregnated fiber-glass
thermoplastic
insulation
insulation
insulation
insulation
(SF-2, 302 °F [150 °C]
(SF-2, 302 °F [150 °C]
wire)
wire)
Wire
Connectors with
Connectors with
Connectors with
Connectors with
connectors
polyvinylidene fluoride
nylon insulation
polyvinylidene fluoride
nylon insulation
(PVDF)
(PVDF)
Supply cable
Type DPS-3 or TPS-3
Type LSDHOF-3 or
Type DPS-3 or TPS-3
Type LSDHOF-3 or
of MIL-DTL-24643/26
LSTHOF-3 of
of MIL-DTL-24643/26
LSTHOF-3 of
MIL-DTL-24643/3
MIL-DTL-24643/3
Cable
Aluminum washers and
Nylon washers and
Aluminum washers and
Nylon washers and
entrances
cap. Dimensions shall
cap as specified in
cap. Dimensions shall
cap as specified in
be as specified in
ASTM F1836M
be as specified in
ASTM F1836M
ASTM F1836M
ASTM F1836M
3.12 400-Hertz fluorescent lighting fixtures. When specified (see 6.2), the procedures specified herein shall
apply when 400-hertz in lieu of 60-hertz fluorescent lighting fixtures are required.
3.12.1 Symbol numbers. A "-400 hertz" for standard fixtures or a "HT-400 hertz" for high-temperature
fixtures shall be placed next to the symbol numbers specified in the applicable specification sheets to indicate a
400-hertz modification of the standard 60-hertz lighting fixtures. (Example: Symbol Number 77.4-400 hertz for
standard fixtures or 77.4 HT-400 hertz for high-temperature fixtures.)
3.12.2 Component substitution. The 60-hertz ballasts specified in the applicable specification sheets shall be
substituted with corresponding 400-hertz ballasts in accordance with MIL-DTL-16377/72 and MIL-F-16377/45.
Other component substitution for high-temperature fixtures shall be as listed in table III.
3.13 Workmanship. The fixtures, lights, and parts shall be manufactured and finished in a manner that is
consistent with best industry practices. Particular attention shall be paid to neatness and thoroughness of soldering,
wiring, marking of parts and assemblies, plating, painting, machine screw assemblage, welding, and freedom of
parts from burrs and sharp edges. See Guideline 9 of MIL-HDBK-454 for additional information regarding
workmanship.
23
