MIL-DTL-16377 Fixtures, Lighting; And Associated Parts; Shipboard Use, General Specification ForThis specification covers fluorescent, incandescent lighting and solid state lighting \(SSL\) \(see 6.12.4\) luminaires and associated parts for legacy replacement and new luminaire development fixtures \(lights\) and associated parts, used for detail and general illumination on naval ships and submarines.

Pages 1 - - 52 - 53 - 54 - 55 - 56 - 57 - 58 - 59 - 60 - 61 - 62 - 63 - 64 - 65 - 66|||


MIL-DTL-16377J(SH)
A OR B
MOUNTING BOLTS SHALL BE 3-16
8
1
A ±32
A
2
C
B
L
2
1
C
B ±32
L
HOLES OF SHOCKMOUNTS
Specification Sheet
Symbol Number
A
B
13
MIL-F-16377/5
338.1 and 339.1
4¾
MIL-DTL-16377/6
149.4
9¼
7¼
MIL-DTL-16377/7
70.3 and 336
9¼
4¾
19
MIL-DTL-16377/8
331.1 and 347.2
4¾
MIL-DTL-16377/9
73.3 and 346.2
9¼
7¼
19
MIL-F-16377/10
145.4
7¼
19
MIL-DTL-16377/11
77.4 and 344.2
7¼
19
MIL-DTL-16377/12
333.1, 341.1, and 342.2
9¼
MIL-DTL-16377/14
80.1 and 79.1
9¼
4¾
13
MIL-F-16377/65
81 and 345.2
7¼
13
MIL-F-16377/66
82 and 343.1
9¼
FIGURE 25. Mounting dimensions for standard mounting of fluorescent fixtures.
51
