MIL-DTL-16377J(SH)
SHOCKMOUNT
SHOCKMOUNT STOP
HOUSING
COMMERCIAL O-RING
DOME WASHER
GASKET SIZE AN6227-5
HEX NUT
SHOCKMOUNT ASSEMBLY
1
18 DIA.
3
32 MIN.
17 MIN. FLAT
32
CLEARANCE HOLE
1
FOR #4 SCREW
INTERNAL
EXTERNAL
TOOTH
TOOTH
1
17
2 DIA.
8
WASHER, INTERNAL - EXTERNAL TOOTH,
DOME TYPE, 0.04 MIN. THICK, STEEL.
13 DIA. X 0.050
32
DEEP FOR O-RING
0.257 DIA. HOLE FOR
SHOCKMOUNT BOLT
1"
+0.005
0.075 -0.003
DEEP
DETENT
1
142°
1
142°
5
3
3
16
5
32R
16
16
30°
3
32R
INTEGRALLY FORMED
INTEGRALLY CAST
DETAIL SHOWING SHOCKMOUNT STOPS
FIGURE 6. Shockmount installation for type I, class 2 fixture.
38
